TC60 skid steer loader
CHUANMU TC60
Product Parameters & English Detail Copy
Product Parameters
| Parameter | Value |
| Overall dimensions | 3350 × 1720 × 2150 mm |
| Wheelbase | 991 mm |
| Tread | 1500 mm |
| Ground clearance | 185 mm |
| Total weight | 3000 kg |
| Maximum speed | 12 km/h |
| Rated hydraulic flow | 75 L/min |
| Operating weight with bucket | 2800 kg |
| Dumping height | 2400 mm |
| Maximum unloading angle | 40° |
| Departure angle | 20° |
| Engine | Xinchai 498 |
English Detail Page Copy
01 Product Hero
| Headline | HIGH-FLOW SKID STEER PERFORMANCE |
| Supporting Copy | More hydraulic capacity for demanding attachments and faster cycles. |
| Selling-point Labels | 75 L/MIN HYDRAULIC FLOW | 2400 MM DUMP HEIGHT | 12 KM/H MAX SPEED |
02 Jobsite Agility
| Headline | BROADER STANCE. JOBSITE AGILITY. |
| Supporting Copy | A 1500 mm tread and compact dimensions balance stability with maneuverability. |
| Selling-point Labels | 3350 × 1720 × 2150 MM | 991 MM WHEELBASE | 1500 MM TREAD | 185 MM GROUND CLEARANCE |
03 Hydraulic Productivity
| Headline | MORE FLOW FOR MORE PRODUCTIVITY. |
| Supporting Copy | 75 L/min rated flow powers responsive handling and demanding attachments. |
| Selling-point Labels | 75 L/MIN RATED FLOW | 3000 KG TOTAL WEIGHT | ATTACHMENT-READY AUXILIARY CIRCUIT |
English Detail Page Copy – Continued
04 Dumping Performance
| Headline | LOAD HIGHER. DUMP CLEAN. |
| Supporting Copy | 2400 mm dumping height and 40° unloading angle keep cycles efficient. |
| Selling-point Labels | 2400 MM DUMPING HEIGHT | 40° MAX UNLOADING ANGLE | TRAILER-READY REACH |
05 Operator Control
| Headline | PROTECTED CONTROL FOR LONG SHIFTS. |
| Supporting Copy | A guarded cab, work lights and direct controls support operator focus. |
| Selling-point Labels | PROTECTIVE CAB | CLEAR SIGHTLINES | WORK LIGHTS | 20° DEPARTURE ANGLE |
06 Attachment Versatility
| Headline | HIGH FLOW. WIDER APPLICATIONS. |
| Supporting Copy | 75 L/min auxiliary capacity supports a versatile attachment lineup. |
| Selling-point Labels | QUICK ATTACH | MULTI-JOB | EASY CHANGEOVER | CONSTRUCTION | MATERIAL HANDLING | SITE CLEANUP |
